PedalGroup–GasolineVehicleACCELERATORANDBRAKEPEDALGROUP
PEDALGROUP–GASOLINEVEHICLE
SeeGeneralWarningsonpage1-2.
PEDALGROUPREMOVAL
1.Disconnectbatteryandsparkplugwire(s).
SeeDisconnectingtheBattery-GasolineVehiclesonpage1-3.
2.Removescrews(1).Pulloormatretainer(3)awayfromthevehicle(Figure5-3,Page5-4).
3.Pulloormat(2)overthepedalgrouptogainaccesstothepedalgrouphardware.
4.Removefastener(10)andliftoffcoverplate(7)(Figure5-4,Page5-5).
5.Loosenjamnuts(4and5)oneachsideofturnbuckle(6).
NOTE:Nut(4)hasaleft-handthread.
6.Loosenturnbuckle(6)untilthethreadedrod(8)fromthepedalgroup(11)isfreeoftheturnbuckle(Figure5-4,
Page5-5).
1
2
3
629
Figure5-3PedalGroupAccess
7.Loosentwonuts(9)ontheacceleratorcableandliftthecablefromitsmountingbracket.
8.Removetwoscrews(2)onthedriversideofthepedalgroupandtwoscrews(1)onthepassengersideof
thepedalgroup.
9.Disconnectsix-pinconnector(12)fromthrottlepositionsensor.
10.Releasetheendoftheacceleratorcable(13)fromthepedalgroup.
11.Liftpedalgroupfromvehicle.
Page5-42019PrecedentVillager2MaintenanceandServiceManual

Club Car Precedent Villager 2 Specifications

General

Model	Precedent Villager 2
Seating Capacity	2
Power Source	48-volt DC (Electric)
Overall Length	91.5 inches
Ground Clearance	4.5 in (11 cm)
Power Source (Electric)	48-volt DC
Batteries	6 x 8V
Charger	Onboard
Forward Speed (Nominal)	14-19 mph
Steering	Rack and Pinion
Tires	18 x 8.5-8
Overall Width	47 in (119 cm)
Turning Radius	10 ft (305 cm)
