ARIZONA VORTEX
USER’S GUIDE
(TRADITIONAL)
HEAD ASSEMBLY
1/2” Head Pins with
ball-lock fully
extended.
Align the orange Gin Pole
Head and the blue A-Frame
Head together at the
connection points.
Once connected, the Gin Pole
Head can rotate to change the
angle of the Easel-Leg relative
to the A-Frame Legs.
Pin the heads together,
ensuring the pins lock
properly.
A
B
C
D
