CMC ARIZONA VORTEX KIT - LEGS TO FEET ASSEMBLY; Correct Flat Foot Position; Correct Raptor Foot Position

ASSEMBLY
LEGS TO FEET
EXPERT USE ONLY
This is the last hole >>>
Both the Raptor Foot and Flat Foot
will connect with the Inner Leg and
Outer Leg.
Inner Leg shown connected
to Raptor Foot.
The ball joint of the Flat Foot should not be set
at its limit of articulation without ensuring that
further movement will not occur.
Outer Leg shown
connected to Raptor
Foot.
Outer Leg shown
attached to Flat Foot.
Inner Leg shown
attached to Flat Foot.
OUTER Leg
A
FLAT
Foot
C
Correct Position of FLAT Foot
G
INNER Leg
B
RAPTOR
Foot
D
E
H
I
F
The Raptor Foot should be
positioned to ensure greatest
grip onto the surface.
Correct Position of RAPTOR Foot
J
