MAN. 181 rev. 3 Use and maintenance manual Sup24 2 di 77
KEY FOR THE SYMBOLS USED IN THE IN THE STICKERS
1 CW rotation / external leveling
2
R
eturn and
l
owering Boom
1 /
backwards travel left crawler
3
Extension and lifting
B
oom
1 /
forward travel left crawler
4 CCW rotation / internal leveling
5 MEWP electrical feeding indicator
6
Led
for the early warning
-
achievement of max. performance
7
Led
for the block when reaching the
maximum performance
8 Load limiting device blck led
9 Endothermic motor start button
10 Electric motor start button
11
Button
for the
automatic
destabilization from the basket
12 Second velocity button
13
Button for the automatic
stabilization from the basket
14
operations with jib
-
d
ead man
button
15 ON/OFF button for travel
16
Leveling operations
–
dead man
button
17 "back home" button
18/24
Joystick (
lt
)
for the operations of
extension/return boom 2 and basket
rotation
19 stabilization consent pilot light led
20 MEWP use consent light led
21/25
Joystick (
lt
)
for the operations of
travel of the right crawler,
lifting/lowering boom 2, basket
leveling
22 Error/failure light led
23 Low gas oil light led
26 Right front outrigger button
27 "stabilization" dead man button
28 Right rear outrigger button
29 “destabilization" dead man button
30
Tasto ON/OFF
button
-
enabling/disabling radiocontrol
31 Crawlers widening button
32 Crawlers return button
33 Left rear outrigger button
34 Left front outrigger button
