CMC S19 User Manual

MAN. 126 rev.4 Use and maintenance manual S19 8 of 77
1  Specifications 


1.1 

 Technical sheet and performances 


Brand of the platform
CMC s.r.l.
Model of the platform
S19
Max capacity load
200 kg (including: nr. 2 persons + tools)
Max height from level ground, to the floor
of the basket
16,45 m
Max. horizontal outreach with 200 Kg
7.80 m (at the edge of the basket)
Turret rotation
+/- 180 °
Basket size
1400 mm x 700 mm
height = 1100mm
Basket rotation*
+/- 90°
Max lifting and descending speed of the MEWP
0,4 m/s (1.31 ft/s)
max extension and retraction speed
0,4 m/s (1.31 ft/s)
Max rotation speed
0,7 m/s (2.3 ft/s)
MAX TRAVEL SPEED
0,3 m/s (0.98 ft/s)
Max manual force allowed in the basket with two operators
400N (89.92 lb)
Tightening torque
Bolts of the bearing
M16 cl 10.9
28 daNm (206 lbf in)
(µ=0.15)
Worst case max possible load under one outrigger
1800 daN
Max specific pressure under the outriggers (without
pads)
7,2 daN/cm2
Transversal travel on slope (MAX)
13° (25 %)
Block at 14°
Max slope travel allowed
10° (18 %) Block at 11°
Max operational inclination allowed by the
chassis frame
1°
Block at 4°
Engine
KUBOTA Z602
10,8 kW a 3200 rpm
(REFER TO THE INCLUDED USER
MANUAL)
Battery
type
voltage / capacity
Lead-acid
12 V/ Ah
Electric system voltage 12 V
220V 20A Electric motor power 2.2 kW
Max operating hydraulic pressure 230 bar/3336 psi
