5  Markings 
On the machine there are the following marks.

 
 Before using the MEWP, it is compulsory to check the presence
and the perfect readability of these marks. In case of absence or
decay of the marks, contact the Servicing.
TYPE Sup MANUFACT. CMC
MODEL Sup19 YEAR 2011
SERIAL NO.
S12A1014 TOT. WEIGHT 2650 Kg
CAPACITY 200 Kg INCLUDING 2 PERS.
MAX MANUAL FORCE ALLOWED 40 daN
MAX WIND SPEED ALLOWED 12,5 m/s
MAX FRAME INCLINATION ALLOWED 1 °
EXTERNAL FEEDING 220V 50Hz
C.M.C. s.r.l.
CARATTERISTICHE
S.P. 231 Km1+ 900
70026 Modugno (BA) - ITALY
Tel./ Fax 080.53.26.606/ 557
http://www.cmclift.com
E-mail: info@cmclift.com
Picture 46: identification plate
Picture 47: work diagram
