19
4
60
61 62 63 64 65 66 67 68 69 70 71
5 72 73 74 75 76 77 78 79 80 81 82 83
6 84 85 86 87 88 89 90 91 92 93 94 95
7 96 97 98 99 100 101 102 103 104 105 106 107
8 108 109 110 111 112 113 114 115 116 117 118 119
9 120 121 122 123 124 125 126 127
6.3 Using knobs and faders
z When you adjust a knob or a fader, it will send specific MIDI data to change related
parameter.
z When you adjust a knob or a fader, you will see related information on the DISPLAY.
z Please refer to the appendix <Intial status> for more information.
You can customize the MIDI data to be sent using the 【ASSIGN】function (8.1).
6.4 Using SEQ control buttons
z Press the SEQ control buttons to send specific MIDI data.
z Please refer to the appendix <Intial status> for more information.
You can customize the MIDI data to be sent using the 【ASSIGN】function (8.1).
6.5 Using function shortcut buttons
z Press the function shortcut button F1～F6 to send specific MIDI data.
z Please refer to the appendix <Intial status> for more information.
You can customize the MIDI data to be sent using the 【ASSIGN】function
(8.1-8.3).
6.6 Pitch wheel and modulation wheel
z Use the pitch wheel to send the pitch bend data by default, and the pitch bend range
is up one semi-note and down one semi-note.
z Use the modulation wheel to send the modulation data.
You can customize the MIDI data to be sent using the 【ASSIGN】function (8.1).
6.7 Pedal
z For the two pedal jacks, each one can be used for continuouls pedal (e.g volume
pedal) or switch pedal (e.g sustain pedal).
z By default, PEDAL A is for sustain pedal and send CC#64 message, the data value
is either 0 or 127(switch data); PEDAL B is for volume pedal and send CC#11
