30
12 U-CTRL mode
Notes for the U-CTRL mode：
z You can control popular computer software in the U-CTRL mode. In this mode,
knobs, faders and buttons will send out preset control data.
z Operation：
【SHIFT】ÖB3
【U-CTRL】, then the indicators around the data knobs will be in
the U shape to show the U-CTRL mode. Repeat the operation again to quit from
the U-CTRL mode.
Launch your computer software, and follow the software’s manual to load the
MackieControl template.
Set the remote control port in the template as “USB AUDIO DEVICE（2）”
(Device name for the instrument)
z Please refer to the list below regarding the MackieControl function map:
UF v2 part MCU part
SLIDER 1-9 SLIDER 1-9
JOG WHEEL JOG WHEEL
F1 BANK LEFT
F2 BANK RIGHT
F3 CHANNEL LEFT
F4 CHANNEL RIGHT
F5 PREVIOUS
F6 NEXT
SHIFT+F1-F6 F1-F6
EXIT READ
ENTER WRITE
SHIFT+EXIT LEFT
SHIFT+ENTER RIGHT
REW REWIND
FF FAST FWD
STOP STOP
PLAY PLAY
REC RECORD
RTZ RTZ
