Table 6. Burning information display description
2.3 Indicator and Beeper status description
Offline writer uses indicator light and buzzer state to represent the state information in the process of using the
writer. For the indicator state, please refer to the table of components on the panel of the burner host, and the
buzzer state description that shown in the table below
Table 7. Beeper status description
Warning
tone
Tip state Description
“Beep”
once
The burner is ready or
already successfully
burned.
1.
After startup: beep, it means that the recording machine is
ready for USB configuration or chip burning starts.
2. Burning process: beep indicates that burning is successful,
and the green light lights up.
No.
LCD display
character
Description
1
0
（SN setting
disable）
Indicates that the already burned consecutive chip numbers, the values are
based on decimal integer.
Each burn was automatically added to one with a maximum number of
4294967295, and recounted from 0 after exceeding the maximum value.
When WriterConfig downloads the user program and configuration data again,
the count will be cleared to zero.
FFFF0123456789B5
（SN setting enable）
When SN Settings Enable，it will display the current SN number to be burned.
2 CMT216xA
Series number, covering the applicable chip model: CMT2168A、
CMT2163A、CMT2160A、CMT2189BE、CMT2189D
3
7_0 The corresponding value for burn options (tick)
18AB Represents the checksum of the contents of the burn program.
