GR712RC-QSG
November 2018, Version 1.0
12 www.cobham.com/gaisler
0x80000b0c DMA descriptor pointer register 0x00000000
0x80000b14 DMA revision register 0x00010001
0x80000b80 Control register 0x00000000
0x80000b84 Status register 0x00000000
0x80000b88 Configuration register 0x001affdf
0x80000b90 Physical layer register 0x00000000
0x80000b94 Coding sub-layer register 0x00000000
0x80000b98 Attached Synchronization Marker 0x352ef853
0x80000ba0 All frames generation register 0x00000000
0x80000ba4 Master frame generation register 0x00000000
0x80000ba8 Idle frame generation register 0x00000000
0x80000bd0 OCF register 0x00000000
Memory controller with EDAC
0x80000000 Memory config register 1 0x0003c0ff
0x80000004 Memory config register 2 0x8ac05460
0x80000008 Memory config register 3 0x08174000
LEON3 Debug Support Unit
0x90000024 Debug mode mask register 0x00000003
0x90000000 CPU 0 Control register 0x000000ef
0x90400020 CPU 0 Trap register 0x000000b0
0x90100000 CPU 1 Control register 0x6911d034
0x90500020 CPU 1 Trap register 0x6911d034
Generic FT AHB SRAM module
0x80100000 Configuration Register 0x00200000
Generic UART
0x80000104 UART Status register 0x00000086
0x80000108 UART Control register 0x80000003
0x8000010c UART Scaler register 0x0000009b
Multi-processor Interrupt Ctrl.
0x80000200 Interrupt level register 0x00000000
0x80000204 Interrupt pending register 0x00000000
0x80000210 Interrupt status register 0x180c0002
0x80000240 Interrupt mask register 0 0x00000000
0x80000244 Interrupt mask register 1 0x00000000
0x80000280 Interrupt force register 0 0x00000000
0x80000284 Interrupt force register 1 0x00000000
Modular Timer Unit
0x80000300 Scalar value register 0x0000002f
0x80000304 Scalar reload value register 0x0000002f
0x80000308 Configuration register 0x00000144
0x80000310 Timer 0 Value register 0xffffffff
0x80000314 Timer 0 Reload value register 0xffffffff
0x80000318 Timer 0 Control register 0x00000043
0x80000320 Timer 1 Value register 0x00000000
0x80000324 Timer 1 Reload value register 0x00000000
0x80000328 Timer 1 Control register 0x00000040
0x80000330 Timer 2 Value register 0x00000000
0x80000334 Timer 2 Reload value register 0x00000000
0x80000338 Timer 2 Control register 0x00000040
0x80000340 Timer 3 Value register 0xfa16f3e8
0x80000344 Timer 3 Reload value register 0xfffffffe
0x80000348 Timer 3 Control register 0x00000040
SPI Controller
0x80000400 Capability register 0x01001002
0x80000420 Mode register 0x00000000
0x80000424 Event register 0x00000000
0x80000428 Mask register 0x00000000
0x8000042c Command register 0x00000000
0x80000430 Transmit register 0x00000000
0x80000434 Receive register 0x20880021
General Purpose Register
0x80000600 GR712RC general purpose register 0x00000000
General Purpose I/O port
0x80000900 I/O port data register 0x419ff955
0x80000904 I/O port output register 0x00000000
0x80000908 I/O port direction register 0x00000000
0x8000090c I/O interrupt mask register 0x00000000
0x80000910 I/O interrupt polarity register 0x00000058
0x80000914 I/O interrupt edge register 0x00001100
0x80000918 I/O bypass register 0x00000000
General Purpose I/O port
0x80000a00 I/O port data register 0xfff19ad9
0x80000a04 I/O port output register 0x00000000
0x80000a08 I/O port direction register 0x00000000
0x80000a0c I/O interrupt mask register 0x00000000
0x80000a10 I/O interrupt polarity register 0x00000001
0x80000a14 I/O interrupt edge register 0x0000e00c
0x80000a18 I/O bypass register 0x00000000
AMBA Wrapper for OC I2C-master
0x80000c00 Clock prescale register 0x0000005f
0x80000c04 Control register 0x00000000
0x80000c08 Receive register 0x00000000
0x80000c0c Status register 0x00000000
