COBHAM GR712RC Quick Start Guide

GR712RC-QSG
November 2018, Version 1.0
14 www.cobham.com/gaisler
| 1 | GRSPW | Spacewire link 0 | 0 | 1 | 0 |
| 2 | GRSPW | Spacewire link 1 | 0 | 1 | 0 |
| 3 | GRSPW | Spacewire link 2 | 0 | 0 | 1 |
| 4 | GRSPW | Spacewire link 3 | 0 | 0 | 1 |
| 5 | GRSPW | Spacewire link 4 | 0 | 0 | 1 |
| 6 | GRSPW | Spacewire link 5 | 0 | 0 | 1 |
| 7 | CAN | CAN core 1 & 2 | 0 | 0 | 1 |
| 8 | SatCAN | SatCAN controller | 0 | 0 | 1 |
| 9 | GRTM | Telemetry Encoder | 0 | 0 | 1 |
| 10 | GRTC | Telecommand Decoder | 0 | 0 | 1 |
| 11 | B1553BRM | MIL-STD-1553 BRM | 0 | 0 | 1 |
+------+----------+----------------------------+----------+---------+-------+
grmon2> grcg enable 0
grmon2> grcg
GRCLKGATE GR712RC info:
Unlock register: 0x00000000
Clock enable register: 0x00000007
Reset register: 0x00000ff8
GR712RC decode of values:
+------+----------+----------------------------+----------+---------+-------+
| Gate | Core(s) | Description | Unlocked | Enabled | Reset |
+------+----------+----------------------------+----------+---------+-------+
| 0 | GRETH | 10/100 Ethernet MAC | 0 | 1 | 0 |
| 1 | GRSPW | Spacewire link 0 | 0 | 1 | 0 |
| 2 | GRSPW | Spacewire link 1 | 0 | 1 | 0 |
| 3 | GRSPW | Spacewire link 2 | 0 | 0 | 1 |
| 4 | GRSPW | Spacewire link 3 | 0 | 0 | 1 |
| 5 | GRSPW | Spacewire link 4 | 0 | 0 | 1 |
| 6 | GRSPW | Spacewire link 5 | 0 | 0 | 1 |
| 7 | CAN | CAN core 1 & 2 | 0 | 0 | 1 |
| 8 | SatCAN | SatCAN controller | 0 | 0 | 1 |
| 9 | GRTM | Telemetry Encoder | 0 | 0 | 1 |
| 10 | GRTC | Telecommand Decoder | 0 | 0 | 1 |
| 11 | B1553BRM | MIL-STD-1553 BRM | 0 | 0 | 1 |
+------+----------+----------------------------+----------+---------+-------+
