Outline drawings
A-6 Appendix A: Technical specifications 98-148248-C
A.2 Outline drawings
A.2.1 ADU
Figure A-1: Outline drawing: ADU
LTR DESCRIPTION DATE APPROVAL
REVISIONS
ANGLES LIN. DIM. MATERIAL
DR. CH. AP. AP.
FIRST ANGLE PROJECTION
Title:
Size:
Codeident no.: Drawing no.:
Sheet: 1 of 1
Telecommunications Engineering Copenhagen Denmark
A1
NEXT ASSY USED ON
APPLICATION
UNLESS OTHERWISE SPECIFIED DIMENSIONS ARE IN MILLIME- TRES AND TOLERANCES ARE IN ACCORDANCE WITH DS/ISO 2768-1 F
1
2
3
4
1
2
3
4
D
C
B
A
D
C
B
A
99-121451 Rev.A
110
907
200
18 74
200
220
226
818
A-01 Original 20170822 TOB
20170822 20170822 20170822
OUTLINE DRAWING
SAILOR 60GX/600Ka/600Ku
TT94-156941
Scale: 1:5
TOB
CMP
TOB
THREAD for GROUNDING
M10 (depth: 22mm)
SCALE 1:10
