Operation – SAILOR 6004 Control Panel
12 Chapter 2: Operation 98-137261-F
To set up filters for stations do as follows:
1. From any list of messages (Unread, Tagged or All), tap the menu icon and
then Filters.
2. Tap Printer, Display or INS to select the output for this filter.
3. For automatic filtering select Automatic Mode.
The coast stations within the currently set range are displayed.
1
4. For manual selection deselect Automatic Mode and tap the frequency you
want to set up a filter for, e.g. 490 kHz Stations.
Swipe and select the stations you want to receive on this frequency.
5. Tap Apply. The selected stations are displayed directly below the frequency.
To change the Range and select Stations in Automatic Mode, do as follows:
1. From any list of messages (Unread, Tagged or All), tap the menu icon, and
then Settings. The tab Automatic Mode is accessible.
2. Tap the field Range.
3. Swipe until the desired range (min. 50Nm) in Nautical Miles and tap Apply.
4. To include specific stations in Nav Areas, swipe and tap the respective Nav
Area.
5. Swipe and select or deselect the stations to be included in Automatic Mode.
Figure 11: Filters for stations
1. For Automatic Mode the SAILOR 6390 Navtex Receiver must have a valid
GNSS input. Without a valid GNSS input it can only filter manually.
Make sure that the stations for Printer are also included in the
stations for Display. If not, SAR, Nav or Met warnings sent only to
the Printer cannot be displayed and read.
