29 LX MAX Specifications
4544
Frequency Ranges
GENERAL
CHANNELS CB - 40 CH
FREQUENCY RANGE CB - 26.965 TO 27.405 MHZ
WX - 162.400 TO 162.775 MHZ
FREQUENCY TOLERANCE 0.005 %
FREQUENCY CONTROL PLL (PHASE LOCK LOOP) SYNTHESIZER
OPERATING TEMPERATURE
RANGE -30° C TO + 50° C
MICROPHONE Plug-in Electret
INPUT VOLTAGE 13.2VDC nom. negative ground
Current Drain Transmit: AM full mod., 1.5A (maximum)
Receive: Squelched, 0.3A;
full audio output, 1.2A (nominal)
Size ..............................................................8-5/8” D x 7-9/32” W x 2-13/63” H
Weight
..........................................................4 lbs.
Antenna Connector
.................................UHF; SO-239
Meter
.............................................................Indicates relative
power output received
signal strength, and vswr
TRANSMITTER
Power Output ............................................4 watts
Modulation
.................................................AM (Amplitude Modulation)
Frequency Response
...............................300 to 3000 Hz
Output Impedance
..................................50 ohms, unbalanced
RECEIVER
Sensitivity ....................................................Less than 1 µV for 10 dB (S+N) /N
Selectivity
....................................................6 dB @ 7 KHz, 60 dB @ 10KHz
Image Rejection
........................................80 dB, typical
Adjacent-Channel Rejection
................60 dB, typical
IF Frequencies
...........................................Double Conversion: 1st: 10.695 MHz
2nd: 455 KHz
Automatic Gain Control (AGC) ............Less than 10 dB change in audio
output for inputs from 10 to 50,000
microvolts
RF Gain range ............................................40 db
Noise Blanker
.............................................RF type
Squelch
........................................................Adjustable; threshold less than 1µV
Audio Output Power
...............................4 watts
Frequency Response
...............................300 to 3000 Hz
Distortion
....................................................Less than 7% @3 watts @ 1000 Hz
Built-in Speaker
.........................................8 ohms, 5w
External Speaker (Not supplied)............ 8 ohms; disables internal speaker
when connected
(SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE)
The Cobra 29 LX MAX transceiver represents one of the
most ad vanced AM two-way radios used as a Class D
station in the Citizens Radio Service. This unit features
advanced Phase Lock Loop (PLL) circuitry providing com-
plete cov er age of all 40 CB chan nels.
1 26.965 21 27.215 1 162.550
2 26.975 22 27.225 2 162.400
3 26.985 23 27.255 3 162.475
4 27.005 24 27.235 4 162.425
5 27.015 25 27.245 5 162.450
6 162.500
6 27.025 26 27.265 7 162.525
7 27.035 27 27.275 8 161.650
8 27.055 28 27.285 9 161.775
9 27.065 29 27.295 10 163.275
10 27.075 30 27.305
11 27.085 31 27.315
12 27.105 32 27.325
13 27.115 33 27.335
14 27.125 34 27.345
15 27.135 35 27.355
16 27.155 36 27.365
17 27.165 37 27.375
18 27.175 38 27.385
19 27.185 39 27.395
20 27.205 40 27.405
Channel Channel
CB Freq. CB Freq. WX Freq.
Channel In MHz Channel In MHz Channel In MHz
29LX_MAX_MANL.indd 44-45 10/27/16 4:03 PM
