While pressing the speaker terminal levers of the unit, insert the 3.
bare wire into the hole, then release the lever to secure the con-
nection.
The speaker wire and terminal for each speaker is color-coded for 4.
your convenience. The following table will help you match the
speakers to their proper terminal:
Terminal Speaker Color
SW Subwoofer Green
CEN Center Red
SR Surround Right Blue
SL Surround Left Yellow
FR Front Right Blue
FL Front Left White
Make sure that the terminals are connected to the bare wires
and not the insulation. Always match colored positive (+) ter-
minals together; and match black negative (-) terminals to-
gether. If switched, the sound will be out of phase and will not
be produced correctly. Do not connect more than one wire to
each speaker terminal; do not connect one speaker to several
terminals.
Connections
