- 17 -
System Connections
Connecting the Power Adapter
This unit is powered via the AC adapter (supplied). See the below figure for details:
1. Connect the AC adapter to the jack marked with “DC 12V IN” on the rear panel of the
unit.
2. Plug the two-prong end of the power cord to the grounded electrical socket.
3. When not using the unit, turn off the power of the unit first, and then unplug the power
supply to prevent malfunctions.
