- 8 -
Front Panel
9. Remote Sensor
Receives the remote control signal for operation.
10. Display panel
Displays the time, status, radio frequency and radio station number.
When adjusting volume, the volume level will be displayed on the display panel for
several seconds.
11. SEARCH –/+ button
In the radio mode, press once to tune the frequency backward or forward. Press and
hold for about 1.5 seconds to search for radio stations backward or forward
automatically.
In the DVD mode, press the button to activate fast backward or forward playback.
12. MUTE button
Press to turn the speaker output on or off. “MUTE” will be displayed on the display
panel.
13. TIME button
When the time is not shown, press once to display the time on the display panel.
Press it again to set the time on the display panel. Use the /buttons to select the
editing position of hour or minute, and then use the / buttons to adjust the value of
the hour or minute upward and downward.
14. SET button
Press to exit from the timer setup. Press to save the station in the AM/FM mode.
15. _/_ button
Press to select items in the setup menu.
Press to select channels or radio stations in the TV or the radio mode.
Press to adjust the value when setting the time on the display panel.
16. _/_ button
Press to select items in the setup menu.
Or press to adjust the volume. Or press to adjust the value in the picture setup menu.
17. TV/LCD SETUP button
Press to enter the LCD setup menu.
18. OK button
Press to confirm selections in the setup menu. This is the same function as the
“ENTER” button on the remote control.
19. LCD screen
Displays high-resolution pictures
