Code Alarm ca6554 - Pin Output Harness

10 ca6554 Install revA
3 VIOLET/BLACK AUX 1
This wire provides a ( - ) 200mA output capable of driving relays. For Control of
optional accessories (i.e. Power Window/Sunroof, etc.).
 Toactivaterefertothetransmitterbuttoncongurationchart.Pleaserefertothe
selectable options for timing.
4 RED/WHITE TRUNK RELEASE OUTPUT ( - )
Locate the vehicle’s trunk release wire at the trunk release switch.
 Verication:This wire will register either positive voltage or ground when
the trunk release is activated.
 Thisisalowcurrent200mAoutputandincongurableinoptionprogramming.
2 BLUE/BLACK START STATUS / ACTIVE OUTPUT ( - )
This wire provides a ( - ) 200mA output when the remote start function is activated
and remains until 4 seconds after the remote start is shutdown. If this wire will be
used for multiple application’s a 1 amp diode is required in-line with the stripe facing
the control module.
6 Pin Output Harness
1 BROWN/BLACK HORN OUTPUT ( - )
Locate the vehicle’s horn wire.
 Verication:This wire will register at positive voltage and register
ground when the horn switch is pressed.
Connect the BROWN/BLACK wire to the vehicle’s horn wire. This is a low current
output, 200mA.
