Code Alarm ca6554 - Pin AUX Output Harness

152014 Voxx Electronics Corporation. All rights reserved.
4 Pin AUX Output Harness
1 PINK/BLACK AUX 5
This wire provides a ( - ) 200mA output capable of driving relays. For Control of
optional accessories (i.e. Power Window/Sunroof, etc.).
 Toactivaterefertothetransmitterbuttoncongurationchart.Pleaserefertothe
selectable options for timing.
2 ORANGE/BLACK AUX 4
This wire provides a ( - ) 200mA output capable of driving relays. For Control of
optional accessories (i.e. Power Window/Sunroof, etc.).
 Toactivaterefertothetransmitterbuttoncongurationchart.Pleaserefertothe
selectable options for timing.
3 GRAY/BLACK AUX 3
This wire provides a ( - ) 200mA output capable of driving relays. For Control of
optional accessories (i.e. Power Window/Sunroof, etc.).
 Toactivaterefertothetransmitterbuttoncongurationchart.Pleaserefertothe
selectable options for timing.
4 WHITE/BLACK AUX 2
This wire provides a ( - ) 200mA output capable of driving relays. For Control of
optional accessories (i.e. Power Window/Sunroof, etc.).
 Toactivaterefertothetransmitterbuttoncongurationchart.Pleaserefertothe
selectable options for timing.
