Security Trigger Zones
IfthesecuritysystemhasbeentriggeredtheLEDwillashoneofthepatternsbelow
indicating the zone.
LED FLASHES TRIGGER ZONE
2 Flashes Hood / Trunk Input
3 Flashes Door Input
4 Flashes Shock Sensor
5 Flashes Ignition Input
Remote Start Shutdown Diagnostics
Iftheremotestartshutsdownorfailstostart,theparkinglightswillashoneofthe
patterns below indicating the shutdown input.
To manually enter diagnostics and view the last shutdown, turn the ignition ON and
press and release the button.
LED FLASHES SHUTDOWN ZONE
3 Flashes Hood Input
Brake Input
Neutral Safety Input
4 Flashes Remote Start Valet Mode
5 Flashes Manual Transmission Mode not set (manual
transmission models only)
7 Flashes Tach not learned / Crank Average not learned
