Code Alarm ca6554 - Additional Ports; Antenna; LED; Programming Port; Telematic Interface Port

20 ca6554 Install revA
Data Bus Interface Port
This 4 pin port is used for Flashlogic Door Lock and Transponder Databus Interfaces
to communicate with the vehicle’s Databus. When using the DBI port to control the
Flashlogic Door Lock and Transponder Interface modules the following options may
be available. Please refer to the D2D (Data to Data) function list available per vehicle
on the tech service web site.
Tach Input Brake Safety Shut Down
Door Trigger Trunk/Hatch Open
Door Lock Control Passlock / Passkey Interface (GM Only)
Dome Light Supervision Transponder Interface Activation
Factory Alarm Arm / Disarm Diesel Glow Plug Input
Manual Arm / Disarm Inputs (factory keyless controls system)
Antenna / LED / Programming Port
Mount the supplied antenna/receiver to a clear spot on the vehicle’s windshield that
will not block the driver’s vision. A good location is usually high on the windshield
near the rear view mirror. Be careful not to mount the antenna/receiver on any
metallicwindowlm,asthiswilleffectsystemrange.Routetheantenna/receiver
cable to the control module and plug into the antenna port.
Additional Ports
Telematic Interface Port
This 4 pin port is used for telematic Interface accessories, such as Car Connection
Pro, which can control some of the following features.
Door Lock Control Trunk Release
Sliding Doors AUX Output
Car Find Remote Start
