Code Alarm ca6554 - Wire Connection Guide; 4 Pin Main Harness; 6 Pin Start Harness; 6 Pin Output Harness

52014 Voxx Electronics Corporation. All rights reserved.
6 Pin Start Harness
4 Pin Main Harness
6 Pin Output Harness
1
WHITE/RED PARKING LIGHT INPUT
2
WHITE PARKING LIGHT OUTPUT
3
BLACKGROUND
4
BROWNSIREN OUTPUT ( + )
4 PIN MAIN
1
PURPLE STARTER OUTPUT - MOTOR SIDE
2
RED BATTERY 12V ( + )
3
ORANGE ACCESSORY 1 ( + )
4
PINK/WHITE IGNITION 2 ( + )
5
RED/WHITE BATTERY 12V ( + )
6
PINK IGNITION 1 ( + )
6 PIN START
1
BROWN/BLACKHORN OUTPUT ( - )
2
BLUE/BLACK START STATUS / ACTIVE OUTPUT ( - )
3
VIOLET/BLACK AUX 1 OUTPUT ( - )
4
RED/WHITETRUNK RELEASE OUTPUT ( - )
5
LT GREEN/BLACK FACTORY DISARM / PULSE BEFORE START ( - )
6
ORANGE GROUND WHEN ARMED OUTPUT ( - )
6 PIN OUTPUT
