Code Alarm ca6554 - 8 Pin Input Harness; 4 Pin Alternate Output Harness; 4 Pin AUX Output Harness; 3 Pin Lock Output Harness

6 ca6554 Install revA
8 Pin Input Harness
3 Pin Lock Output Harness
4 Pin Alternate Output Harness
1
BLUE UNLOCK ( - )
2
OPEN
3
GREEN LOCK ( - )
3 PIN
LOCK
4 Pin AUX Output Harness
1
BLACK/YELLOWPULSE DURING CRANK ( - )
2
GREEN/WHITE PULSE AFTER SHUTDOWN ( - )
3
LT BLUEFACTORY ARM / PULSE AFTER START ( - )
4
LT GREEN/BLACK FACTORY DISARM / PULSE BEFORE START ( - )
4 PIN
ALTERNATE
OUTPUT
1
PINK/BLACK AUX 5 OUTPUT ( - )
2
ORANGE/BLACK AUX 4 OUTPUT ( - )
3
GRAY/BLACK AUX 3 OUTPUT ( - )
4
WHITE/BLACKAUX 2 OUTPUT ( - )
4 PIN AUX
OUTPUT
1
BLUE/WHITE INSTANT TRIGGER INPUT ( - )
2
GREEN DOOR TRIGGER INPUT ( - )
3
PURPLE DOOR TRIGGER INPUT ( + )
4
WHITE/BLUE EXTRENAL START INPUT ( - )
5
GRAY HOOD PIN INPUT ( - )
6
GRAY/RED PARKING BRAKE INPUT ( - )
7
BROWN/REDBRAKE INPUT ( + )
8
PURPLE/WHITE TACH INPUT
8 PIN INPUT
