CB 2 Series
Administrator Guide
14 How to Replace LED Light Connectors
As of 2020, Code Blue strobe, area and faceplate lights come with Wago connectors. These con-
nectors provide ease of use and a much stronger connection. Below are the steps needed to
change to the new connectors. Each new LED light should come with both the plug-and-socket
Wago connectors.
Example:
Cut off both wires.
Wago plug connectors that
are already connected to the
LED light wires.
Wago socket
connectors to
add to your wires.
To Next Page
