Code Victory 3 User Manual

Victory 3_en.pdf http://en.codelight.com.cn
24
7> Press [Confirm] after finished setting all parameters. You can find the new
user-defined effect from ‘User Effects’. The attribute types (IPCGBES) of the effect
will be listed on the left top corner of the user effect grid.
8> When running a user effect, all attributes included will be listed separately on the ‘Current Loaded
Effects’. You may set up their parameters individually.
6.4.2. Save Running Effects
The option allows you to save the running effects as a user effect.
You can recall the user effect for other fixtures to get the same effect. However, all parameters are based on the
number of running fixtures. You can modify the parameters if the quantity is different.
6.4.3. Label
You may rename the user effect by the option [Label].
6.4.4. Delete User Effects
 Select [Delete User Effect] can delete one of the user effects.
 Select [Delete All User Effects] can delete all the user effects.
Note: If you want to delete one of the user effects, you can also use the Delete key then select the effect shows in
the ‘Effects’ window.
Tap on the
effect

Code Victory 3 Specifications

Display

screen size	15 inches
screen type	capacitive LCD touch screen

Power

power supply voltage	AC100-240V
power supply frequency	50-60Hz

Weight and Dimensions

size	665mm × 580mm × 205mm
net weight	15 Kg
