Press the ENTER key when this display is shown, the display will now show one of the averages. Use the 
and  keys to select the average time that requires changing, and press the ENTER key to change it. The value
can now be changed using the  and  keys and input by pressing the ENTER key.
5 SET AVERAGES
Set the seconds averaging stack to the required value. This is limited to within 10 to 60 seconds in 10-second
intervals.
5 SET AVERAGES
secs 60
Set the minutes averaging stack to the required value. This is limited to within 1 to 60 minutes in 1-minute
intervals.
5 SET AVERAGES
mins 60
Set the hours averaging stack to the required value. This is limited to within 1 to 24 hours in 1-hour intervals.
5 SET AVERAGES
hours 24
Set the days averaging stack to the required value. This is limited to within 1 to 30 days in 1-day intervals.
5 SET AVERAGES
days 30
7.9.3.
Configure O/P1
The analogue current loop output (terminals 19 & 20), is set up from this mode. Press the ENTER key while this
display is shown to select it, then press the  and  keys to step through the available options. Press the
ENTER key to enter each option and change the displayed parameter.
5 CONFIGURE O/P1
7.9.3.1.
Base of Output
An origin of 0 or 4mA can be set for the current loop output. The  and  keys will toggle between these two
options. Press the ENTER key to enter the new value.
5 CONFIGURE O/P1
Output = 4 to 20mA
