32 DataMan 200 Quick Reference Guide DataMan 200 Quick Reference Guide 33
RS-232 Cable
The RS-232 cable provides an optional connection between the reader and your
PC. It also provides access to the digital input line (In1).
2
4
RxD
3
GND
TxD
1
IN_1
3
RxD
2
TxD
5
GND
235
IN_1
GND
(RS-232)
2.74K
2.74k
1.0K
+3.3V
10K
28V Max. Across input pins - Transition approx. 12V (Min)
Weight 75 g
Operating
Temperature
0ºC — 40ºC (32ºF — 104ºF)
Storage
Temperature
-10ºC — 60ºC (-14ºF — 140ºF)
Maximum
Humidity
95% (non-condensing)
Environmental IP65 (with cable or protection cap attached to all three connectors)
None (C-mount option)
Vibration EN61373 including IEC 60068-2-6,60068-2-64 6.4, and 60068-2-27
Codes Data Matrix
TM
(IDMax: ECC 0, 50, 80, 100, 140, and 200; IDQuick:
ECC200)
Vericode (optional)
QR Code and microQR Code
UPC/EAN/JAN
Codabar, Interleaved 2 of 5, Code 39, Code 128, and Code 93, Pharma,
Postal, RSS/CS, PDF 417, MicroPDF 417
Discrete I/O
operating limits
HS Output
0,1
I
MAX @ 24 VDC 50 mA
RMAX @ 12 VDC 150 Ω
@ 24 VDC 470 Ω
Input 0 (Trigger)
Input 1
V
IH ±12 — ±28 V
VIL 0 — ±8 V
ITYP @ 12 VDC 2.0 mA
@ 24 VDC 4.2 mA
Power Supply
Requirements
PoE injector Class 1 or 48VDC
2.0W Max LPS
Ethernet Speed 10/100
Duplex Mode Full duplex or half duplex
DataMan 200 Specications
8
IN_1
