DataMan 280 Readers with 16 mm lens
The following tables list the Field of View (FoV) widths of the 16 mm lens at various
distances:
Working distance in mm Horizontal values in mm
Vertical values in mm
Z
1
= 150 X
1
= 46 Y
1
= 34
Z
2
= 225 X
2
= 69 Y
2
= 52
31
