Connecting the Power and I/OBreakout Cable
CAUTION: To reduce emissions, connect the far end of the Breakout cable
shield to frame ground.
Note:
l Perform wiring or adjustments to I/O devices when the reader isnot
receiving power.
l You can clip unused wires short or use a tie made of non-conductive
material to tie them back. Keep bare wires separated from the
+24VDC wire.
1. Verify that the 24VDC power supply is unplugged and not receiving power.
2. Attach the Power and I/O Breakout cable's +24VDC and Ground wires to
the corresponding terminals on the power supply. For more information,
see Specifications on page41.
CAUTION: Never connect voltages other than 24VDC. Always
observe the polarity shown.
3. Attach the Power and I/OBreakout Cable's M12 connector to the reader's
24 VDC connector.
4. Restore power to the 24VDC power supply and turn it on if necessary.
Using your device through USB
For a detailed description, see the DataMan 280 Reference Manual.
