Cognex DataMan 282 - DataMan 280 Series Reader Image Sensor

DataMan 280 Series Reader Image Sensor
Specification
DataMan 280 DataMan 282
Image Sensor
1/3-inch CMOS, global shutter 1/3-inch CMOS, global
shutter
Image Sensor
Properties
Diagonal size: 6.21 mm
Pixel size: 3.45 μm (H) x 3.45 μm (V)
Diagonal size: 6.17 mm
Pixel size: 2.8 μm (H) x 2.8
μm (V)
Image Resolution
(pixels)
1440 x 1080 (1.6 mp) 1920 x 1080 pixels (2 mp)
Electronic Shutter
Speed
Minimum exposure: 29 μs
Maximum exposure: 10 ms (with internal illumination)
Maximum exposure: 200 ms (with external illumination)
Image Acquisition at
Full Resolution
Maximum: 45 Hz
Lens Type
6.2 mm (3 pos or LLM), 16 mm (manual or LLM), 6.2 mm
UV, 6.2 mm and 16 mm IR, C-Mount acc.
8 mm, 12 mm, 16 mm High
Speed Liquid Lens
43
