DataMan 282 Readers with 8 mm Lens
Working distance in mm Horizontal values in mm
Vertical values in mm
Z
1
= 300 X
1
= 223 Y
1
= 125
Z
2
= 750 X
2
= 526 Y
2
= 295
Z
3
= 1200 X
3
= 828 Y
3
= 466
Working Distance in mm 2D min. code in mil 1D min. code in mil
300 12 7
750 18 12
1200 22 15
