Cognex VisionView Web - Visionview Web HDMI Layout

Element Description
1 10/100/1000 Mbps Ethernet
2 DC-IN +8 V ~ 35 V
3 Power switch
4 USB 2.0 ports
5 Micro SD slot (does not support CF)
VisionView Web HDMI Layout
The following table shows the layout for the VisionView Web HDMI:
Element Description
1 SD card slot
2 USB 2.0 ports
3 PowerLED
4 SD/eMMC LED
7
Getting Started
