Cognex VisionView Web - Dimensions

Element Description
5 Power switch
6 Power supply (DC +12 V ~ +36 V)
7 HDMI output port
8 RJ-45 Ethernet port
Dimensions
VisionView Web Panel Dimensions
The following figure shows the dimensions for the VisionView Web Panel.
8
Getting Started
