5
5
5
5
5
5
100
A
A
5
5
5
5
5
5
1
1
3
2
7
1
5
1
3
2
6
1
7
1
3
2
1
1
2
1
4
1
215
2175
SECTION A-A
SUPPORT BEAM
10
1
1260
860
RATCHET CARGO BELT
DETAIL B
SCALE 1 : 6
*
*
9
4
8
4
NOTE:
USE EUR PALLET AND WOODEN CABINETS
10
1
FOR SHIPPMENT
1.
COMPLETE FRAME SHOULD BE FIXED AND SECURED BY 2x RATCHET CARGO BELT.
2.
FIX FOOTS
*
*
TO PALLET
3.
REVISIONS
REV.
DESCRIPTION
DATE
IN ITIALS
A
ITEM NO.
PART NUMBER
Description
1/QTY.
1 514700
FRONT PANEL 2 WITH BRACKETS
1
2 514744
Cabinet sheet top PR120H, COMPLETE
1
3 514747
Frontplade, nederst, PR120H, COMPLETE
2
4 514746
Cabinet sheet, side, PR 120 H, COMPLETE
1
5 514745
Cabinet sheet, Frontside, PR 120 H,
COMPLETE
1
6 514701
FRONT PANEL WITH BRACKETS
1
7 514696
COMPLETE FRAME AND BRACKETS
PR120H
1
8 500141
DIN 125A, M20, A2
4
9 81368
Hexagon nut, DIN 934, M20, A2
4
10 514748
WOODEN BOX AND PALLET
1
PROPRIETARY AND CONFIDENTIAL:
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF ICETECH A/S. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF ICETECH A/S IS PROHIBITED.
514703
Article nr.:
Copy from:
Industrivej 62
DK-6740 Bramming
TLF. +45 76561500
FAX. +45 76561509
www.icetechworld.com
-
Material:
P294-1-20227
1/2
Sheet no:
Projection:
A3
Creator:
Rev:
A
Date:
Scale:
Weight:
471.47 kg
1:20
Description:
FRAME AND CABINETS PR120H
Format:
lm
Drawing no.:
IceTech A/S
18-09-17
