PROPERTY OF COLD JET, LLC. IT IS NOT TO BE
WAS ORIGINATED BY, AND IS THE EXCLUSIVE
JET, LLC.
THE EXPRESS WRITTEN CONSENT OF COLD
OPTICAL, MANUAL, OR OTHERWISE, WITHOUT
BE ELECTRONIC, MECHANICAL, MAGNETIC,
IN ANY FORM OR BY ANY MEANS, WHETHER IT
COMPUTER LANGUAGE IN WHOLE OR IN PART,
TRANSLATED INTO ANY OTHER LANGUAGE OR
STORED IN A RETRIEVAL SYSTEM, OR
REPRODUCED, TRANSMITTED, TRANSCRIBED,
RESERVED. NO PART OF THIS DESIGN MAY BE
COPYRIGHT© COLD JET, LLC. ALL RIGHTS
INTERESTS OF COLD JET, LLC.
USED IN ANY WAY DETRIMENTAL TO THE
THE DESIGN CONTAINED IN THIS DRAWING
7
4
8
4
16
4
3
1
5
1
4
1
12
4
2
1
5
1
6
1
9
4
11
4
15
1
10
1
1
2
13
1
14
1
NOTES:
CLEAN THE THREADS ON THE STUD BOLTS AND APPLY SEMI-PERMANENT THREAD SEALING COMPOUND
1.
TO THE THREADS ON THE END THAT IS SCREWED IN THE ALUMINIUM HOUSE.
TIGHTEN THE STUD BOLT BY HAND.
2.
APPLY ANTI-SEIZE FOOD GRADE COMPOUND AFTER CLEANING THE THREADS.
3.
FOLLOW THIS PROCEDURE FOR MONTING THE DIE PLATE:
4.
STEP 1. CROSS TENSION THE 4 MAIN NUTS TO TORQUE 37 FT-LBS (50 NM)
STEP 2. CROSS TENSION THE 4 MAIN NUTS TO TORQUE 148 FT-LBS (200 NM)
STEP 3. TENSION THE 4 LOCKING NUTS TO TORQUE 74 FT-LBS (100 NM)
5. APPLY VASELINE/SILICONE BASED COMPOUND TO THE O-RING TO KEEP IT IN PLACE DURING ASSEMBLY
SEE NOTE #2
SEE NOTE #1
SEE NOTE #3
SEE NOTE #1
SEE NOTE #2
SEE NOTE #3
SEE NOTE #1
SEE NOTE #2
SEE NOTE #3
15
472.90
98
REVISIONS
REV.
DESCRIPTION
DATE
IN ITIALS
E
Updated BOM and annotations
19-03-2019
Hmh
ITEM
QTY.
PART #
DESCRIPTION
1 2 502137
PROP, MS E29-5 1/2'' WITH O-RING
2 1 511427
Housing for extruder cylinder
3 1 511445
Extruder cylinder 01
4 1 511446
Degassing filter elemen, 40 my
5 1 511447
O-ring
6 1 511448
Extruder cylinder 02
7 4 511456
Nut DIN439 M20x1,5 A2
8 4 511457
Nut DIN934 M20x1,5 A2
9 4 513567
Press Bushing 22
10 1 516018
Cylidrical adapter PR120
11 4 516020
Stud bolt DIN939 M20x1,5 L160
12 4 516021
Stud Bolt DIN939 M20x1,5 L70
13 1
5C0028
O-RING D=133 MM, d= 3MM
14 1
5C0029
O-RING D=96MM, d= 3 MM
15 1
5C0030
O-RING D=146MM, d=5mm
16 4 81369
WASHER, STANDARD FLAT, M20, STAINLESS STEEL
F
SHEET
1 OF 1
SIZE:
PROJECTION:1ST ANGLE
MATERIAL:
CREATED BY:
APPROVED BY:
COPIED FROM:
WEIGHT: Kg
PART NUMBER:
PROJECT:
REVISION:
DESCRIPTION:
DATE:
-
A2
DATE:
511439
EXTRUDER CYLINDER
42.94
3/6/2022
H. HANSEN
DIMENSION TOLERANCE ACC.
TO DS/ISO 2768-1 M
GEOMETRIC TOLERANCE ACC.
TO DS/ISO 2768-2 K
A A
B B
C C
D D
6
6
5
5
4
4
3
3
2
2
1
1
SCALE:
1:5
