PARTS IDENTIFICATION
Code No. Description Code No. Description
1724350 (TTA) Contactor - motor 1722210 (ITR) Circuit breaker
1724350 (TTC) Contactor - compressor 1722310 (TEC/TE1) Temperature sensor
3213090 (TRI) Transformer 1722990 (TR2) Transformer 24/11 Volt
1727720 Microprocessor/ Eprom 1722020 (CPU) Electronic board
1722350 (MIP) Safety magnetic switch 1722400 Suppressor elect. interference
3213500 (TRA) Current Transformer 1724670 (RTA) Overload
1722200 (F1-F2) Fuse - 1 Amp.
FigureG
