Section 3 Installation
3-2
Cole Palmer
Electrical
Requirements
The unit construction provides protection against the risk of electrical
shock by grounding appropriate metal parts. The protection will not
function unless the power cord is connected to a properly grounded
outlet. It is the user's responsibility to assure a proper ground
connection is provided.
The unit is intended for use on a dedicated outlet.
NOTE If the circuit protector activates allow the unit to cool before
resetting. Restart the unit. Contact us if it activates again.
The circuit protection is designed to protect the controller, and is not
intended as a substitute for branch circuit protection. Position the unit so it is
not difcult to operate the disconnecting device.
If the unit's power cord is used as the disconnecting device, it must be
easily accessible at all times.
Refer to the unit nameplate on the rear, upper-left-hand corner of the
unit for specic electrical requirements. Voltage deviations of ± 10%
are permissible. The outlet must be rated as suitable for the total power
consumption of the unit, see below.
The following power options are available:
Unit Volts
1
/Hertz/Phase Amps
2
Total Wattage Plug Type
C6/C6F 115/60/1 12 1328 N5-15
1 230/50/1 12 1573 Country Specific
C6/C6F 115/60/1 12 1328 N5-15
3 230/50/1 12 2373 Country Specific
C15 115/60/1 12 1345 N5-15
1/2 230/50/1 12 1596 Country Specific
C15 115/60/1 12 1345 N5-15
3 230/50/1 12 2396 Country Specific
C15++ 115/60/1 16 1662 N5-20
1/2 230/50/1 12 1798 Country Specific
C15++ 115/60/1 16 1662 N5-20
3 230/50/1 12 2598 Country Specific
All Heated Units 115/60/1 12 1104 N5-15
1/2 230/50/1 12 1338 Country Specific
All Heated Units 115/60/1 12 1304 N5-150
3 230/50/1 12 2138 Country Specific
1. Volts ± 10%
2. Maximum amp draw
