Appendix
5
Cole Palmer
Table 3 READ STATUS
BIT d1 d2
b.7 Low Temp Fault
b.6 High Temp Fault HTC Fault
b.5 Low Temp Warning MOL Fault
b.4 High Temp Warning Pump Speed Fault
b.3 RTD2 Open/Short High RA Temp
b.2 RDT1 Open/Short HPC Fault
b.1 Unit Faulted Low Level Fault/Warning
b.0 Unit Running High Level Fault/Warning
Unit of Measure
Index Unit
0 NONE
1 Temperature in °C
2 Temperature in °F
3 Flow liters per minute
4 Flow in gallons per minute
5 Time in seconds
6 Pressure in PSI
7 Pressure in bars
8 Resistivity in MΩ-cm
9 %
10 Volts
11 Pressure in kPa
