Coleman FC9M080C16UP11 - ELECTRICAL AND PERFORMANCE DATA

259720-CTG-B-0108
Unitary Products Group 3
* ESP (External Static Pressure) .5" WG is at furnace outlet ahead of cooling coil.
Annual Fuel Utilization Efficiency (AFUE) numbers are determined in accordance with DOE Test procedures.
Wire size and over current protection must comply with the National Electrical Code (NFPA-70-latest edition) and all local codes.
The furnace shall be installed so that the electrical components are protected from water.
NOTES:
1. For altitudes above 2000 ft. reduce capacity 4% for each 1000 ft. above sea level.
2. Wire size based on copper conductors, 60°C, 3% voltage drop.
3. Continuous return air temperature must not be below 55°F.
4. All filters must be high velocity cleanable type.
5. Air flows above 1800 CFM require either return from two sides or one side plus bottom.
ELECTRICAL AND PERFORMANCE DATA
Models
Input
Max/Min
Output
Max/Min
Blower
Size
Blower
Max.
Over-current
Protect
Air Temp. Rise
Maximum Input
Air Temp. Rise
Minimum Input
MBH MBH In. HP Amps °F °F
FC9M060B12UP11 60/21 57/20 11 x 8 1/2 7.7 20 40 - 70 20 - 50
FC9M080B12UP11 80/28 76/26 11 x 8 1/2 7.7 20 40 - 70 20 - 50
FC9M080C16UP11 80/28 76/26 11 x 10 3/4 10.2 20 40 - 70 20 - 50
FC9M100C16UP11 100/35 95/33 11 x 10 3/4 10.2 20 40 - 70 20 - 50
FC9M100C20UP11 100/35 95/33 11 x 11 1 12.8 20 40 - 70 20 - 50
FC9M120D20UP11 120/42 115/39 11 x 11 1 12.8 20 40 - 70 20 - 50
Models
Max. Outlet
Air Temp.
Nominal
Airflow
Cabinet
Width
Total
Unit
AFUE
Min. Wire Size
(awg) @ 75 ft.
One Way
Approximate
Operating Weight
Power Supply
(Voltage-PH-Hz)
°F CFM In. Amps %
FC9M060B12UP11 170 1200 17-1/2 9 95.0 14 135 115-1-60
FC9M080B12UP11 170 1200 17-1/2 9 95.0 14 142 115-1-60
FC9M080C16UP11 170 1600 21 12 95.0 14 157 115-1-60
FC9M100C16UP11 170 1600 21 12 95.0 14 162 115-1-60
FC9M100C20UP11 170 2000 21 14 95.0 12 164 115-1-60
FC9M120D20UP11 170 2000 24-1/2 14 95.0 12 180 115-1-60
