When the Collamat
®
6600 is connected to the terminal, it must be switched on. At this
moment the DIL-switch TEST must be set to on. The traction unit begins to turn with the
speed set on the SPEED potentiometer. The terminal shows the following message:
COLLAMAT 6600 V1.011
Motor intervall test. Use spacebar to leave
Pressing the spacebar stops the motor intervall test. Now the following help menue will
be displayed:
Helpmenue for C6600 Testprogram
-------------------------------
H : Help
M : Motortest
N : Motor intervall test
B : BUS-signal selftest
S : Signals display
D : DIL-switch settings
O : Potentiometer parameters
P : Potentiometer settings
I : Incrememtalencoder
E : EEPROM Data
V : Version and Serial-No
Select Testfunctions with the Keys H,M,N,B,S,D,O,P,I,E,V
>
The testfunctions can be called with the appropriate keys. All testfunctions can be stop-
ped with the spacebar.
Motortest
The Motortest is used for measuring the phase currents of the motor. The motor turns
with the speed set on the SPEED potentiometer.
>m
Motortest. Use spacebar to leave
