Motor intervall test
The Motor intervall test tests the labelling functions of the Collamat
®
6600. If a label
web is threaded through the dispenser, labels will be dispensed periodically with the
speed set on the SPEED potentiometer.
>n
Motor intervall test. Use spacebar to leave
BUS-signal selftest
The BUS-signal selftest tests all in- and outputs of the Collamat
®
signalbus. For this test
a diagnostic connector (see figure 17) must be plugged into the busconnector X102 (left
side).
Attention:
To avoid damage of peripheral units or sensors, all sensors and bus-
cables must be removed from the connectors.
>b
BUS-signal selftest
Testing FEED+LSC......OK
Testing FEED+READY....OK
Testing TCY+GSC1......OK
Testing NSTPO+GSC2....OK
Testing CLK+NSTPI.....OK
ERROR and IFEED signals blink until spacebar is pressed
This test will display faulty signalpairs on the terminal screen. If the test is started
without the diagnostic connector the following message is displayed:
>b
BUS-signal selftest
Testing FEED+LSC......not OK !
Testing FEED+READY....not OK !
Testing TCY+GSC1......not OK !
Testing NSTPO+GSC2....not OK !
Testing CLK+NSTPI.....not OK !
ERROR and IFEED signals blink until spacebar is pressed
5999.527-01A 25.11.98 WM Seite 20 / 32
