Collamat 3600 - Page 23

EEPROM Data
This test checks the EEPROM and displays its data. (The data are volatile !)
>e
EEPROM Data
Test EEPROM : Ok !
Addr: 0000 0001 0002 0003 0004 0005 0006 0007
Data: 0631 0057 0287 0119 1E03 6501 6400 0078
Addr: 0008 0009 000A 000B 000C 000D 000E 000F
Data: FFFF FFFF FFFF FFFF FFFF FFFF 0007 AAAA
Version and Serial-No
This test shows the firmware version, the release date and the serial number of the con-
troller print.
>v
Version and Serial-No.
COLLAMAT 6600
Version : V1.011
Date : 25. Juni 1996
Serial No.: 0007
Potentiometer parameters
On the Collamat
®
6600 the potentiometers can be programmed. With this function the
working range of the potentiometers can be matched to a special labelling condition. To
enable the potentiometer programmability, the DIL-switch TEST must be set to ON.
The following table shows the standard potentiometer range with its upper and lower
values.
Potentiometer Standardvalue Parameter Range
min. max. Range min. max. min. max.
SPEED
3 m/min 30 m/min 27 m/min 3 m/min 30 m/min 3 m/min 27 m/min
PREDISP.
0 mm 100 mm 100 mm 0 mm 250 mm 25 mm 250 mm
POSITION
0 mm 100 mm 100 mm 0 mm 250 mm 25 mm 250 mm
5999.527-01A 25.11.98 WM Seite 22 / 32
