Colortrac SMARTLF SCAN - Page 24

24

DOCUMENT NO
.
88N001G © 2016 Colortrac

5
1
3 4
2
MAINTENANCE CLEANINGTHESCANNER





















STEPS
Pushleftandrightleversdownwardstolowertheclosedtraysection 1
Supporttrayandfoldoutlowersection 2
Identifywhitepaperpressureplate(sprung ) 3
Identifysensorglass 4
Periodicallyinspectandclean3and4usingnon‐abrasive,non‐solvent,lint‐
freecleaningproducts ifrequired 
5
Allowtodrythenclosetray(checkforbluelightwhenpoweredbackup)


