Colortrac SMARTLF SCAN - One-Time Calibration

9

DOCUMENT NO
.
88N001G © 2016 Colortrac

2
1
3
INSTALLATION
CALIBRATION(ONE‐TIME)


























STEPS
Alwaysensure sensorglass isclean anddry (see maintenance section if
youthinktheglassmaybedirty)
1
Note:Calibrationtargetisplacedbetweenwidthmarkers 2
Insertcalibrationtargetintoscannerfaceup,blacksectionfirst 3
Selectsettings,colorcalibration,pressOK
 
Calibrationtargetisejectedaftercalibration

Selectsettings,linecalibration,pressOK
 
Calibrationtargetisejectedfromtherearwhencalibrationiscomplete

