IGS-NT Communication Guide
28
Controllers
Controllers IG-NT-BB IG-NTC-BB IS-NTC-BB IM-NTC-BB IM-NT-BB
Connection
applicable
NO YES YES YES NO
Available
ports
external bridge ETHERNET ETHERNET ETHERNET external bridge
More info IG/IS/IM-NTC-BB - Communications (page 12)
Controllers IG-NT IG-NTC IS-NT-BB IM-NT
Connection
applicable
NO NO NO NO
Available
ports
external bridge external bridge external bridge external bridge
Note: Ethernet connection is available for all mentioned controllers via external bridge or IB-NT (see Ethernet
connection via IB-NT on page 34).
Number of clients connected simultaneously
2 clients with InteliMonitor or WebSupervisor (Comap/TCP protocol)
2 clients with web interface
Using a web browser
Ethernet connection to controller makes possible using any web browser for basic monitoring and adjustment of
the controller. Simply put the IP address of the module into the address line in your web browser like
http://192.168.1.254 and then enter access code. In case of connection from web browser there is 5 minutes
timeout after closing the browser window. After that the client is automatically logged out.
Ethernet connection settings
Parameters can be set via any type of connection (USB, RS232, Ethernet). Setup is provided via InteliMonitor.
For Ethernet connection set these parameters in Comms Settings group:
Note: The IP addresses of the controllers must be accessible from the remote computer. If the remote
computer is connected into another LAN segment than the gen-sets are, there must be a gateway(s) that enable
direct traffic between the segments. If the remote computer is connected via Internet, then the internet gateway
of the LAN where gen-sets are connected must have public IP address, must allow incoming traffic and must
provide port forwarding from the external public IP to the different internal gen-set IPs according to the port
used.
