IGS-NT Communication Guide
33
I-LB+ hardware setup
(all jumpers in those positions)
HW/SW control no matter (Open)
ComAp/ModBus Open
ADDR1/ADDR2
Selection of CAN address. Open = ADDR2, Close = ADDR1 (read more about I-LB+
module)
DIRECT/MODEM Open
RS485/RS232 No matter
Comm. speed. No matter
RS485 120 Ohm Open = terminator not connected, Close = terminator connected
CAN 120 Ohm Open = terminator not connected, Close = terminator connected
Controllers
Controllers IG-NT-BB IG-NTC-BB IS-NTC-BB IM-NT-BB IM-NTC-BB
Connectionapplicable YES YES YES YES YES
Available ports USB on I-LB+ USB on I-LB+ USB on I-LB+ USB on I-LB+ USB on I-LB+
More info Comms extension - I-LB+ Local bridge (page 64)
Controllers IG-NT IG-NTC IS-NT-BB IM-NT
Connectionapplicable YES YES YES YES
Available ports USB on I-LB+ USB on I-LB+ USB on I-LB+ USB on I-LB+
More info Comms extension - I-LB+ Local bridge (page 64)
Equipment
Equipment needed
Controller side I-LB+ unit (see Comms extension - I-LB+ Local bridge on page 64)
Connection USB (see USB cable on page 84)
PC side USB connection
