InteliLite Global Guide
179
or
L3 >=100V
Mono Phase
or
L1 >=100V
L2 <= 20V
L3 <= 20V
Voltage Autodetect shutdown
Note: To lock this setpoint against editing you also have to lock setpoint Connection Type 1 (page
329), Connection type 2 (page 333) and Connection type 3 (page 337).
6 back to List of setpoints
Setpoint group Basic settings Related FW 1.9.0
Range [units] 80 .. 20 000 [V]
Default value 231 V Alternative config YES
Step 1 V
Comm object 8277 Related applications AMF, MRS
Config level Standard
Setpoint visibility Conditioned by the setpoint Connection type (page 177).
Description
Nominal voltage (phase to neutral).
Note: To lock this setpoint against editing you also have to lock setpoint Nominal Voltage Ph-N 1
(page 332), Nominal Voltage Ph-N 2 (page 336) and Nominal Voltage Ph-N 3 (page 340).
Nominal Voltage Ph-N
6 back to List of setpoints
Setpoint group Basic settings Related FW 1.9.0
Range [units] 80 .. 40 000 [V]
Default value 400 V Alternative config YES
Step 1 V
Comm object 11657 Related applications AMF, MRS
Config level Standard
Setpoint visibility Conditioned by the setpoint Connection type (page 177).
Description
Nominal system voltage (phase to phase).
Note: To lock this setpoint against editing you also have to lock setpoint Nominal Voltage Ph-Ph 1
(page 332), Nominal Voltage Ph-Ph 2 (page 336) and Nominal Voltage Ph-Ph 3 (page 340).
Nominal Voltage Ph-Ph
6 back to List of setpoints
