InteliLite Global Guide
246
Setpoint group General Analog Inputs Related FW 1.9.0
Range [units] the range is defined by analog sensor curve
Default value
the value is defined by
analog sensor curve
Alternative config NO
Step the step is defined by analog sensor curve
Comm object 11408 Related applications AMF, MRS
Config level Standard
Setpoint visibility Visible only if the logical binary output AIN SWITCH02 (PAGE 553) is configured
Description
Threshold level for switching the binary output AIN SWITCH 02 (PAGE 624) on. The value is measured from
AIN SWITCH 02 (PAGE 624) analog input.
Image 8.22 General analog input 2 switch
Analog Switch 2 On
6 back to List of setpoints
