InteliLite Global Guide
255
Setpoint group General Analog Inputs Related FW 1.9.0
Range [units] the range is defined by analog sensor curve
Default value
the value is defined by
analog sensor curve
Alternative config NO
Step the step is defined by analog sensor curve
Comm object 14963 Related applications AMF, MRS
Config level Standard
Setpoint visibility Visible only if the logical binary output AIN SWITCH04 (PAGE 554) is configured
Description
Threshold level for switching the binary output AIN SWITCH 05 (PAGE 625) on. The value is measured from
AIN SWITCH 05 (PAGE 625) analog input.
Image 8.28 General analog input 4 switch
Analog Switch 5 On
6 back to List of setpoints
