IS-NT-Async-SPI, SW Version 1.2, ©ComAp – February 2011
IS-NT-Async-SPI-1.2.PDF
54
DispBaklightTO [ min ] (FV)
Timeout after which the display backlight is switched off.
OFF = the backlight is off all the time, NO TIMEOUT = the backlight is on all the time.
Step: 1 min
Range: OFF (=0), 1 – 240 min, NO TIMEOUT (=241)
Force value possibility: Yes
DispBklStrtOff [ DISABLED / ENABLED ] (FV)
This setpoint determines if display backlight is switched on/off during the gen-set start. This parameter is
effective for all the displays not only for the internal one.
Force value possibility: Yes
Contr. addr [ ]
Controller CAN bus and RS-485 identification number. Each controller in the group has to have its own
unique number.
Step: 1
Range: 1 to 32
Hint:
When opening Direct or Modem connection to the controller (using PC monitoring/control SW), the Contr.
address has to correspond to the Gen-set setting in PC SW.
RS232(1) mode [ DIRECT / MODEM (HW) / MODEM (SW) /
MODBUS-DIRECT / MODBUS-MDM(HW) ]
Communication protocol selection for RS232(1) line.
DIRECT: Connection to a local PC running InteliMonitor. RS232 or RS485 (with internal or
external converter) lines can be used. Set this also for IG-IB connected via RS232 line.
MODEM (HW): Analog/GSM/ISDN modem connection. Select this for standard modems with HW flow
control. If selected and no CTS signal is detected, communication may not work
correctly.
MODEM (SW): Analog/GSM/ISDN modem connection. Select this for modems without HW flow control
– controller will use SW flow control signals XOn, Xoff, so only TxD and RxD signals
need to be connected between the controller and the modem.
MODBUS-DIRECT:Modbus protocol for direct connection to PLC / external SCADA terminal. Communication
speed can be selected via setpoint RS232(1)MBCSpd.
MODBUS-MDM(HW):Modbus protocol for modem (remote) connection to PLC / external SCADA terminal.
Communication speed can be selected via setpoint RS232(1)MBCSpd.
Hint:
Detail description of Modbus protocol see in Communication guide.
ECU LINK mode can be selected only at one of the RS232 ports at the same time. If selected on both, the
RS232(2) line won’t work.
RS232(2) mode [ DIRECT / MODEM (HW) / MODEM (SW) /
MODBUS-DIRECT / MODBUS-MDM(HW) ]
Communication protocol selection for RS232(2) line.
Description is the same like for RS232(1) mode.
Available only in IS-NT and in IG-xxC versions.
RS232(1)MBCSpd [ 9600 bps / 19200 bps / 38400 bps / 57600 bps]
Defines the communication speed on RS232(1) line when ModBus mode is selected.
RS232(2)MBCSpd [ 9600 bps / 19200 bps / 38400 bps / 57600 bps]
Defines the communication speed on RS232(2) line when ModBus mode is selected. Available only in IS-NT
and in IG-xxC versions.
